MODEL
HN3KS-AH2GT
HN3K6S-AH2GT
HN4KS-AH2GT
HN5KS-AH2GT
HN6KS-AH2GT
Max. PV Input Power(kW)
4.5
5.5
6
7.5
9
Max. PV Open Circuit Voltage(V)
550
550
550
550
550
MPPT Range@Operating Voltage(V)
80~520
80~520
80~520
80~520
80~520
Max. Input Current per MPPT(A)
19/19
19/19
19/19
19/19
19/19
Max. Short-circuit Current(A)
25/25
25/25
25/25
25/25
25/25
MPPT Tracker/Strings
2 / 1
2 / 1
2 / 1
2 / 1
2 / 1
Nominal Output Power(kW)
3
3.68
4
5
6
Nominal Voltage/Frequency
230V(176V~280V), 50/60Hz, L+N+PE
230V(176V~280V), 50/60Hz, L+N+PE
230V(176V~280V), 50/60Hz, L+N+PE
230V(176V~280V), 50/60Hz, L+N+PE
230V(176V~280V), 50/60Hz, L+N+PE
Adjustable Power Factor
0.8leading~0.8lagging
0.8leading~0.8lagging
0.8leading~0.8lagging
0.8leading~0.8lagging
0.8leading~0.8lagging
BatteryVoltage Range(V)
40~60
40~60
40~60
40~60
40~60
Max. Battery Charging/Discharging Current(A)
80/80
80/80
80/80
120/120
120/120
Battery Type
Lithium and Lead Acid Battery
Lithium and Lead Acid Battery
Lithium and Lead Acid Battery
Lithium and Lead Acid Battery
Lithium and Lead Acid Battery
Ingress Protection
IP66
IP66
IP66
IP66
IP66
Operating Temperature Range
-25~60℃
-25~60℃
-25~60℃
-25~60℃
-25~60℃
